About boxplusx

boxplusx illustrates HTML visualization capabilities using plain JavaScript and CSS3.


boxplusx is also integrated into the sigplus Joomla extension available in the Joomla Extensions Directory. If you use the Joomla content management system, you might want to take a look at how to set custom gallery parameters in your sigplus activation tag.

How to use


The following snippet imports minified boxplusx CSS and JavaScript files, compatible with all supported browsers:
<!-- Style definitions -->
<link rel="stylesheet" type="text/css" href="engine/css/boxplusx.min.css" />

<!-- Minified script -->
<script type="text/javascript" src="engine/js/boxplusx.min.js" defer></script>


The following snippet imports boxplusx CSS and JavaScript original source files:
<!-- Style definitions -->
<link rel="stylesheet" type="text/css" href="engine/css/boxplusx.css" />

<!-- Uncompressed script compliant with ECMAScript 6 -->
<script type="text/javascript" src="engine/js/boxplusx.js" defer></script>
JavaScript code is written in ECMAScript 6, which may not be compatible with older browsers, such as Internet Explorer. When minified into production code, JavaScript is cross-compiled to ECMAScript 5, which even older browsers understand. A polyfill script helps if you need to debug in older browsers:
<!-- Polyfill definitions for ECMAScript 6 functions targeting old browsers -->
<script type="text/javascript">
if (/MSIE \d|Trident.*rv:/.test(navigator.userAgent)) {
    document.write('<scr' + 'ipt src="engine/js/polyfill.js" defer><\/scr' + 'ipt>');

<!-- Uncompressed script compliant with ECMAScript 6 -->
<script type="text/javascript" src="engine/js/boxplusx.js" defer></script>


Standalone images

Sample image

Sample image 1 Sample image 2 Sample image 3 Sample image 4

Sample image 4 Sample image 5 Sample image 6 Sample image 7 Sample image 8 Sample image 9 Sample image 10 Sample image 11 Sample image 12
boxplusx includes an initialization script that runs when the page has loaded (or more precisely, when the page structure is available, i.e. DOMContentLoaded). This organizes all anchors that have the same rel attribute value into a gallery. (Attribute values that do not start with the string boxplusx- are ignored to let you opt out of this behavior for certain images.) When you click any item in the gallery, the pop-up window opens and lets you navigate in between images in the same gallery.

Change any of the parameters in the table below to customize how the pop-up window for the above image gallery appears.


Usage from Joomla

The following sigplus activation code shows how to set boxplusx parameters if you choose boxplusx (with light or dark theme) as your lightbox pop-up window engine:

Usage from JavaScript


Sample QuickTime video Sample ogg video Sample YouTube video


The Not So Short Introduction to LATEX2ε

Notice how the URL has name=value parameters like view=Fit after the # sign, which are passed intact to the PDF reader, and let you customize how the PDF appears, see Parameters for Opening PDF Files for a full list.

External content

External content is shown in an HTML iframe.

Wikipedia Map of Budapest University of Technology and Economics, and surrounding area

Use pseudo-parameters width and height in the URL to set a preferred width and height for your iframe, or make the pop-up window take all available browser window area with fullscreen.
Example Behavior
https://example.com?width=800&height=600 Set preferred width to 800px and height to 600px with query string parameters.
https://example.com#width=800&height=600 Set preferred width to 800px and height to 600px with parameters in the HTML fragment (hash string).
https://example.com#width=800&height=600&fullscreen=1 In addition to preferred width and height, make the pop-up window take all available space.

The following examples illustrate fullscreen=1 with various width and height pseudo-parameter values in the URL. Observe how aspect ratio (of width to height) is maintained as the lightbox pop-up window grows to occupy all available space.

Inline content

Inline content is shown in the context of the current window, in an HTML div. You can pass parameters to boxplusx (such as preferred width and height) using the extended fragment identifier syntax (with a hash-bang): #element-name!key1=value1&key2=value2. Inline content for these elements has been embedded in this page, using CSS display: none, a technique you can also apply.

Unavailable content

A special (resizable) image is shown if the content is not available. The image can be customized in CSS.

JPEG image orientation

EXIF orientation is correctly identified for JPEG images, and the image is flipped and rotated as necessary with CSS transforms.
2 3 4 5 6 7 8 1 2 3 4 5 6 7 8

How to use and contribute

boxplusx is hosted on Bitbucket, download or check out to start working or contribute.
